A 10m³ Sinotruk Howo concrete mixer truck with 6×4 drive, WP10.380E22 engine and heavy-duty chassis configuration.
A 10m³ Sinotruk Howo concrete mixer truck with 6×4 drive, WP10.380E22 engine and heavy-duty chassis configuration.
Large concrete delivery, infrastructure construction, ready-mix plants, road and bridge construction.
| Drive Type | 6×4 |
|---|---|
| Engine Model | WP10.380E22 |
| Transmission Model | HW19709XST |
| Vehicle Size | 9020 × 2495 × 3800 mm |
| Wheelbase | 3800 + 1350 mm |
| Curb Weight | 25000 kg |
| Rated Payload | 12000 kg |
| Mixing Drum Volume | 10 m³ |
| Tank Material | Q345B 5mm |
| Rear Axle Model | MCX16ZG double rear axle |
| Front Axle Model | 9.5T |
| Fuel Tank | 400 L |
| Speed Reducer | PMP 6.5 |
| Oil Pump | PMP90 |
| Motor | PMP90 |
| Emission Standard | Euro II |
Need quotation or customization? Contact Wellwo for configuration, delivery and OEM options.
Send the model, market, quantity and destination. This page is set up for direct product inquiry, not generic browsing.
